Smith Fittings, a top-notch manufacturer and supplier located in Canberra, Australia, specializes in high-quality **Stainless Steel 409 Coil and Slitting Coil** that are crafted for outstanding corrosion resistance, strength, and durability. Using cutting-edge technology, these coils are perfect for a variety of industrial and automotive applications. Smith Fittings prides itself on precision engineering, ensuring dimensional accuracy and a superior surface finish in every product. The Stainless Steel 409 Coils comply with international standards and are highly regarded for their performance in high-temperature and oxidizing environments, making them a go-to choice in the construction, fabrication, and exhaust system manufacturing industries.
**Stainless Steel 409 Coil and Slitting Coil** are ferritic stainless steels primarily made up of chromium (10.5–11.75%), along with small amounts of titanium, manganese, and silicon. This unique blend offers solid corrosion and oxidation resistance, as well as enhanced weldability and formability. The alloy boasts a tensile strength of about 380–450 MPa, good ductility, and thermal stability up to 675°C. These coils strike a cost-effective balance between performance and durability, making them ideal for moderate corrosion environments and high-temperature service conditions.
| Standard | ASTM A240, ASME SA240 |
| Thickness | 0.1mm to 12 mm Thk |
| Coil Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc. |
| Coil Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm etc. |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sandblast, Brush, etching. |
| Finish | Hot rolled (HR), Cold rolled (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated), Galvanized etc. |
| Grade | C | Ni | Si | S | Mn | P | Cr | Ti |
| SS 409 | 0.08 max | 0.5 max | 1.00 max | 0.045 max | 1.00 max | 0.045max | 10.5 – 11.75 | 6x C – 0.75 |
| Tensile Strength(MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Rockwell B (HRB) max | Brinell (HB) max |
| 450 | 240 | 25 | 75 | 131 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 409 Coils and Slitting Coils offer excellent corrosion resistance, particularly in moderately corrosive environments like automotive exhaust systems and industrial applications. They are highly heat-resistant, performing well at elevated temperatures without compromising structural integrity. The low carbon content ensures good weldability and prevents carbide precipitation during welding. With a tensile strength of approximately 450 MPa and good formability, these coils are versatile and durable. Their affordability, combined with superior resistance to oxidation, makes them an ideal choice for cost-effective solutions in applications requiring corrosion and heat resistance.
Yes, we offer custom sizes for Stainless Steel 409 Coils to meet specific project needs. Our team at Josh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| Grade | WERKSTOFF NR. | AISI | UNS | AFNOR | BS | GOST | JIS |
| SS 409 | 1.4512 | 409 | S40900 | Z3CT12 | 409 S 19 | SUH 409 | – |
You’ll find **Stainless Steel 409 Coil and Slitting Coil** widely used in automotive exhaust systems, mufflers, catalytic converters, and heat exchangers, thanks to their impressive resistance to high-temperature oxidation. They’re also utilized in construction, agricultural equipment, and industrial machinery where moderate corrosion resistance and strength are essential. Plus, these coils are perfect for fabricating fuel filters, silencer components, and transport equipment. Their blend of affordability, weldability, and heat resistance makes them a dependable material choice for both structural and thermal applications across a range of industries.
