Smith Fittings, a reputable manufacturer and supplier located in Canberra, Australia, proudly offers top-notch **Stainless Steel 348 Angles** that stand out for their remarkable corrosion resistance, high-temperature strength, and overall durability. Designed to meet the rigorous demands of industrial, chemical, and power generation sectors, these angles ensure dependable performance even in oxidizing and mildly corrosive environments. Crafted to meet international standards, Smith Fittings’ Stainless Steel 348 Angles boast exceptional dimensional accuracy, weldability, and mechanical stability. Their unique blend of toughness, thermal resistance, and lasting strength makes them perfect for constructing heat exchangers, boiler components, chemical processing equipment, and structural assemblies that require consistent performance and reliability.
**Stainless Steel 348 Angles** are primarily made of iron, featuring around 18–20% chromium, 9–11% nickel, 2–3% copper, along with trace amounts of carbon, manganese, and silicon. This austenitic stainless steel is known for its excellent corrosion resistance, with a tensile strength ranging from 515–700 MPa and a yield strength of 205–310 MPa, along with good elongation properties. It offers high-temperature stability, toughness, and weldability, making it an ideal choice for industrial, structural, and chemical applications that demand both durability and strength.
Standard – ASTM A240 / ASME SA240, JIS4304-2005, ASTM A167, EN10088-2-2005, GB/T3280-2007, etc
Thickness – 0.3mm – 100mm
Width – 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc
Length – 2000mm, 2440mm, 3000mm, 5800mm, 6000mm etc
Surface – 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc
Material – Soft, Deep Draw, Extra Deep Draw, Quarter Hard, Half Hard, Full Hard.
Finish – Hot rolled plate (HR), Cold rolled sheet (CR), NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA
Form – Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange), etc.
| Grade | Mn | P | C | S | Cr | Si | Ni | Fe | Co |
| SS 348 | 2.0 | 0.045 | 0.080 | 0.030 | 19 | 1.0 | 11 | 66 | 0.2 |
| SS 348H | 2.00 | 0.045 | 0.04-0.10 | 0.030 | 17.00-19.00 | 0.75 | 9.00-13.00 | – | – |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Rockwell B (HR B) max | Brinell (HB) max |
| 348 | 515 | 205 | 40 | 92/95 | 201/217 |
| 348H | 968 (≥) | 423 (≥) | 32 | 34 | 212 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 348 | 1.4550 | S34800 |
| SS 348H | 1.4961 | S34809 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Josh Sheets and Plates based in Canberra, Australia, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless steel 348 angle offers several advantages, including excellent corrosion resistance, especially in high-temperature environments, making it ideal for applications in the chemical, aerospace and petrochemical industries Demonstrates weldability and excellent formability ate, making it easy to manufacture. Intergranular corrosion resistance of the alloy ensures its durability in high temperature applications. Stainless steel 348 also retains its strength at elevated temperatures, making it suitable for use in electric motors and boilers. It is resistant to scaling and oxidation, providing long-term performance under harsh conditions. These qualities ensure reliability and durability.
You’ll find **Stainless Steel 348 Angles** commonly used in chemical processing plants, power generation equipment, marine applications, and various industrial machinery. They serve as excellent structural supports, heat exchangers, boiler components, and equipment that face high temperatures and oxidizing conditions. In the realm of industrial and engineering applications, these angles deliver enduring mechanical strength, corrosion resistance, and dimensional stability. With their impressive toughness, thermal resistance, and weldability, Stainless Steel 348 Angles from Smith Fittings are a trustworthy option for high-performance industrial and structural applications that require durability and operational efficiency.
