Smith Fittings, located in Canberra, Australia, stands out as a top manufacturer and supplier of **Stainless Steel 202 Angles**. These angles are celebrated for their impressive corrosion resistance, robust strength, and budget-friendly performance. Crafted from austenitic stainless steel, they feature a higher manganese content and lower nickel levels, which contribute to their solid mechanical properties while ensuring durability in mildly corrosive settings. At Smith Fittings, precision manufacturing and rigorous quality control are priorities, guaranteeing that their 202 angles meet international standards. Perfect for a range of uses—industrial, architectural, and structural—these angles deliver reliable performance, enduring strength, and versatility, making them ideal for fabrication, construction, and high-performance engineering projects.
**Stainless Steel 202 Angles** are composed of chromium (17–19%), nickel (4–6%), and manganese (7–9%), which together provide outstanding corrosion resistance, mechanical strength, and ductility. They boast a tensile strength of around 520 MPa, a yield strength of 205 MPa, and an elongation of 35%. With a density of 7.9 g/cm³ and a melting range of 1400–1450°C, these angles offer excellent toughness, weldability, and formability, ensuring reliable performance in both industrial and structural applications.
| Specifications | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 202 Angle | 5mm to 9mm |
| Thickness | 3.0mm – 120mm |
| Length | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade 202 | C | Mn | Si | P | S | Cr | Ni | N |
| max. | 0.15 | 7.50-10 | 1 | 0.060 | 0.030 | 17- 19 | 4-6 | 0.25 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min |
| 202 | 515 | 275 | 40 |
| STANDARD | UNS | WERKSTOFF NR. |
| SS 202 | S20200 | 1.4373 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 202 angle offers many advantages, including excellent corrosion resistance, making it ideal for use in wet and chemical environments It has excellent strength and durability, and ensures performance reliability in construction applications. This alloy is cost-effective compared to higher grades like 304, while still providing high resistance to oxidation and turbidity. Stainless Steel 202 is highly versatile, easy to manufacture and maintain, and provides aesthetic appeal. It is commonly used in the construction, design and construction industry, providing a balance of energy and cost.
| Sizes (all Dimensions in milimeter) | Approx Weight SS Angle Bar (kilogram/meter) | SS 202 Angle Bar Sizes (all Dimensions in milimeter) | Approx Weight SS 202 Angle Bar (kilogram/meter) |
| 25 x 25 x 3 | 1.13 | 63 x 63 x 8 | 7.50 |
| 25 x 25 x 4 | 1.46 | 65 x 65 x 4 | 4.00 |
| 25 x 25 x 5 | 1.78 | 65 x 65x 5 | 5.02 |
| 30 x 30 x 3 | 1.37 | 65 x 65 x 8 | 7.75 |
| 30 x 30 x 4 | 1.78 | 70 x 70 x 5 | 5.35 |
| 30 x 30 x 5 | 2.20 | 70 x 70 x 6 | 6.40 |
| 40 x 40 x 3 | 1.83 | 75 x 75 x 6 | 6.85 |
| 40 x 40 x 4 | 2.41 | 75 x 75 x 8 | 9.05 |
| 40 x 40 x 5 | 2.97 | 80 x 80 x 6 | 7.35 |
| 50 x 50 x 4 | 3.05 | 80 x 80 x 8 | 9.65 |
| 50 x 50 x 5 | 3.78 | 80 x 80 x 10 | 11.98 |
| 63 x 63 x 4 | 3.90 | 100 x 100 x 8 | 12.20 |
| 63 x 63 x 5 | 3.90 | 100 x 100 x 12 | 18.00 |
**Stainless Steel 202 Angles** find their place in various applications that demand corrosion resistance, strength, and cost-effectiveness. They are particularly well-suited for architectural frameworks, kitchen equipment, chemical processing machinery, and industrial fabrication. Moreover, they are utilized in structural supports, automotive components, and general engineering tasks where mechanical stability and resistance to oxidizing environments are crucial. Their exceptional performance makes them a go-to choice for industrial, structural, and high-performance engineering projects across a wide array of sectors.
