Smith Fittings, a top-notch manufacturer and supplier located in Canberra, Australia, specializes in high-quality **Nitronic Sheets and Plates** that are designed for exceptional strength, corrosion resistance, and durability. These austenitic stainless steel products are crafted to meet rigorous international standards, ensuring outstanding mechanical performance even in the toughest industrial settings. Smith Fittings takes pride in delivering precise thickness, a consistent surface finish, and dependable material properties, making their Nitronic Sheets and Plates perfect for critical engineering and structural projects. The company serves a variety of industries, including aerospace, chemical processing, marine, and power generation, providing robust solutions that can handle high stress, extreme temperatures, and corrosive environments while ensuring long-lasting performance and reliability.
**Nitronic Sheets and Plates** mainly consist of iron, chromium (around 17–20%), nickel (approximately 8–12%), and nitrogen (about 0.18%), along with trace amounts of manganese and silicon. These sheets and plates boast impressive tensile strength ranging from 620–850 MPa, high yield strength, and remarkable ductility. They offer excellent corrosion resistance, especially in oxidizing and chloride-rich environments, and maintain great toughness and dimensional stability at elevated temperatures. Their unique blend of strength, corrosion resistance, and wear resistance makes them ideal for a wide array of industrial and structural applications.
| Standard : | UNS S21906 | AMS 5656 | MIL-T-9821 | ASTM A276 | ASME SA276 UNS S21800 | Alloy 218 | ASME SA 193 | AMS 5848 | ASTM A 193 EN 1.3964 | ISO 15156-3 | NACE MR0175 | UNS S20910 | AMS 5764 | ASTM A193 | Werkstoff 1.3964 |
| Size : | 20mm x 1200 x 500 |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Nitronic 40 / 50 / 60 (UNS-S20910, S21800, S21900) |
| STANDARD | UNS | EN | ISO | NACE | AMS | ASTM | Werkstoff | other |
| Nitronic 40 | S21906 | – | – | – | 5656 | A276 | – | MIL-T-9821 |
| Nitronic 50 | S20910 | 1.3964 | 15156-3 | MR0175 | 5656 | A193 | 1.3964 | MIL-T-9821 |
| Nitronic 60 | S21800 | – | – | – | 5848 | A193 | 1.3964 | Alloy 218 |
| Weight% | C | P | Si | Ni | Fe | Mn | S | Cr | N | Mo | Cu |
| Nitronic 40 (21-6-9) | 0.04 max | 0.060 max | 1.00 max | 5.5-7.5 | Bal | 8-10 | 0.030 max | 19-21.5 | 0.15-0.40 | 0.75 max | 0.75 max |
| Alloy | Cross Section Size | Test Direction | Yield Strength 0.2% | Ultimate Tensile Strength | Elongation in 2″(%) | Reduction of Area % | Rockwell B Hardness | ||
| ksi | MPa | ksi | MPa | ||||||
| Nitronic 40 (21-6-9) | 6″ (152mm) sq | Longitudinal | 62 | 428 | 95 | 655 | 46 | 69 | |
| Nitronic 40 (21-6-9) | 6″ (152mm) sq | Transverse | 52 | 358 | 93 | 641 | 30 | 45 | |
| Nitronic 40 (21-6-9) | 4″ (102mm) sq | Longitudinal | 56 | 386 | 97 | 668 | 53 | 73 | |
| Nitronic 40 (21-6-9) | 1″ (25.4mm)sq | Longitudinal | 52 | 358 | 101 | 696 | 53 | 73 | 90 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Josh Sheets and Plates based in Canberra, Australia, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Nitronic sheets and plates offer numerous advantages, including exceptional corrosion resistance, making them ideal for harsh environments such as marine and chemical processing industries. They provide excellent strength, toughness, and wear resistance, even at elevated temperatures, which enhances their durability in demanding applications. Nitronic alloys also exhibit superior resistance to galling, ensuring longer service life in mechanical and aerospace components. Their ability to maintain structural integrity under stress and corrosion makes them a reliable choice for industries requiring high performance and longevity, such as aerospace, automotive, and marine.
Yes, we offer custom sizes for Nitronic Sheets and Plates to meet specific project needs. Our team at Josh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
**Nitronic Sheets and Plates** find extensive use in industries that demand high strength, corrosion resistance, and durability. They are frequently utilized in **chemical processing equipment, pressure vessels, and storage tanks**. In the **marine and offshore sectors**, they serve as **structural components, piping systems, and in shipbuilding applications**. Their superior mechanical properties and resistance to wear and corrosion also make them a great fit for **aerospace, power generation, and heavy machinery**.
