Smith Fittings, a reputable manufacturer and supplier located in Canberra, Australia, specializes in high-quality **Monel 400 Channels** that are designed to withstand tough conditions with exceptional corrosion resistance, mechanical strength, and durability, making them perfect for both industrial and marine environments. Crafted to meet strict international standards, these nickel-copper alloy channels boast precise dimensions, a uniform surface finish, and dependable mechanical performance. By blending advanced manufacturing techniques with thorough quality control, Smith Fittings ensures that their products consistently deliver high performance. They cater to various industries, including chemical processing, marine, aerospace, and oil and gas, providing Monel 400 Channels that are ideal for structural support, fabrication, and applications that demand resistance to seawater, acids, alkalis, and oxidation.
**Monel 400 Channels** primarily consist of nickel (about 63–70%) and copper (around 28–34%), along with trace amounts of iron, manganese, and carbon. They showcase impressive tensile strength ranging from 550–750 MPa, yield strength between 200–450 MPa, and remarkable ductility. These channels excel in resisting corrosion from seawater, acids, and alkalis while maintaining their mechanical stability even at high temperatures. Their unique blend of strength, toughness, and formability makes Monel 400 Channels a great choice for critical structural, marine, and industrial applications.
| Specifications | : | ASTM B164 / ASME B164 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Monel 400 Channel | : | 40mm*20mm~300mm*300mm |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | C Channel, U Channel, Channels |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | Cu | Fe | Ni | S |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 28.00 – 34.00 | 2.50 max | 63.00 min | 0.024 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35000 , MPa – 240 | 40% |
Monel 400 Channel offers numerous advantages, including excellent corrosion resistance in marine and chemical environments, making it ideal for harsh conditions. Its high tensile and yield strength ensure durability and reliability under mechanical stress. The alloys resistance to acidic and alkaline substances enhances its versatility in diverse industrial applications. Monel 400 exhibits excellent thermal conductivity and stability, performing well in high-temperature environments. Additionally, it resists stress corrosion cracking and pitting, ensuring a long service life. Its machinability and weldability further simplify fabrication and installation processes.
Yes, we offer custom sizes for Monel 400 Channel to meet specific project needs. Our team at Josh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| STANDARD | MATERIAL NO. | US | HE | GOST | BS | AFNOR | IN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | MNJMc 28-2.5-1.5 | THAT 13 | NO-30M | NiCu30Fe |
**Monel 400 Channels** find extensive use in industries that demand high corrosion resistance, mechanical strength, and thermal stability. They are commonly utilized in **marine structures, pump shafts, valves, and fasteners**. In the **chemical processing and oil & gas sectors**, they serve vital roles in **piping systems, heat exchangers, and structural components**. Their outstanding resistance to seawater, acids, and alkalis also makes them suitable for **industrial machinery, aerospace components, and high-performance engineering applications**. Monel 400 Channels ensure long-lasting durability, dimensional stability, and reliable mechanical performance in even the most challenging environments.
