Josh Sheetsandplates is a top-notch manufacturer and supplier located in Canberra, Australia, focusing on high-quality **Inconel 600 Channels** tailored for demanding industrial applications. Known for their precision, reliability, and cutting-edge manufacturing skills, the company creates materials that excel in extreme conditions, such as high temperatures, oxidation, and corrosive environments. Their Inconel 600 Channels are built to last, offering outstanding durability, structural integrity, and long-term performance, making them perfect for critical projects. Catering to industries like aerospace, chemical processing, power generation, and marine, Josh Sheetsandplates provides customized solutions that guarantee consistent quality, operational efficiency, and top-notch mechanical performance in tough industrial and high-temperature settings.
**Inconel 600 Channels** mainly consist of nickel and chromium, with iron added to enhance strength and corrosion resistance. This alloy boasts high tensile and yield strength, excellent creep and rupture resistance, and good ductility across a broad temperature range. Inconel 600 maintains its structural integrity even under thermal cycling and in corrosive environments, resisting oxidation, pitting, and stress corrosion cracking. It also offers great weldability and formability, making it ideal for applications that require durability, mechanical strength, and reliable long-term performance in extreme industrial conditions.
Specifications : ASTM B166 / ASME SB166
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | UNS | DIN | JIS | BS | GOST | AFNOR | EN |
| Alloy 600 | N06600 | 2.4816 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Alloy 600 | 0.15 max | 1.00 max | 0.50 max | 0.015 max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strengt | Yield Strength (0.2%Offset) | Elongation |
| Alloy 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Josh Sheets and Plates based in Canberra, Australia, is a leading supplier and stockist of high-quality metal products, including sheets, plates, coils, foils, angles, channels, circles, and slitting coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Inconel 600 Channel offers numerous advantages, making it highly sought after in demanding industries. Its exceptional resistance to oxidation and corrosion ensures durability in high-temperature and chemically aggressive environments. The alloy maintains strength and structural integrity under extreme thermal conditions, offering excellent creep-rupture properties. Its versatility allows it to perform effectively in a wide range of applications, including chemical processing, aerospace, and marine industries. Additionally, Inconel 600 resists stress-corrosion cracking and chloride-ion-induced pitting, ensuring long-term performance in challenging environments, thus reducing maintenance and replacement costs.
| Sizes (all Dimensions in milimeter) | Approx Weight Inconel Angle Bar (kilogram/meter) | Inconel Angle Bar Sizes (all Dimensions in milimeter) | Approx Weight Inconel Angle Bar (kilogram/meter) |
|---|---|---|---|
| 25 x 25 x 3 | 1.13 | 63 x 63 x 8 | 7.50 |
| 25 x 25 x 4 | 1.46 | 65 x 65 x 4 | 4.00 |
| 25 x 25 x 5 | 1.78 | 65 x 65x 5 | 5.02 |
| 30 x 30 x 3 | 1.37 | 65 x 65 x 8 | 7.75 |
| 30 x 30 x 4 | 1.78 | 70 x 70 x 5 | 5.35 |
| 30 x 30 x 5 | 2.20 | 70 x 70 x 6 | 6.40 |
| 40 x 40 x 3 | 1.83 | 75 x 75 x 6 | 6.85 |
| 40 x 40 x 4 | 2.41 | 75 x 75 x 8 | 9.05 |
| 40 x 40 x 5 | 2.97 | 80 x 80 x 6 | 7.35 |
| 50 x 50 x 4 | 3.05 | 80 x 80 x 8 | 9.65 |
| 50 x 50 x 5 | 3.78 | 80 x 80 x 10 | 11.98 |
| 63 x 63 x 4 | 3.90 | 100 x 100 x 8 | 12.20 |
| 63 x 63 x 5 | 3.90 | 100 x 100 x 12 | 18.00 |
| Size in Inches | Est. Weight per Ft. Lbs. | Est. Weight per 20′ Bar |
|---|---|---|
| 3/4 x 3/4 x 1/8 | 0.59 | 11.80 |
| 1 x 1 x 1/8 | 0.80 | 16.00 |
| 1 x 1 x 3/16 | 1.16 | 23.20 |
| 1 x 1 x 1/4 | 1.49 | 29.80 |
| 1-1/4 x 1-1/4 x 1/8 | 1.01 | 20.20 |
| 1-1/4 x 1-1/4 x 3/16 | 1.48 | 29.60 |
| 1-1/4 x 1-1/4 x 1/4 | 1.92 | 38.40 |
| 1-1/2 x 1-1/2 x 1/8 | 1.23 | 24.60 |
| 1-1/2 x 1-1/2 x 3/16 | 1.80 | 36.00 |
| 1-1/2 x 1-1/2 x 1/4 | 2.34 | 46.80 |
| 2 x 2 x 1/8 | 1.65 | 33.00 |
| 2 x 2 x 3/16 | 2.44 | 48.80 |
| 2 x 2 x 1/4 | 3.19 | 63.80 |
| 2 x 2 x 3/8 | 4.70 | 94.00 |
| 2-1/2 x 2-1/2 x 3/16 | 3.07 | 61.40 |
| 2-1/2 x 2-1/2 x 1/4 | 4.10 | 82.00 |
| 3 x 3 x 1/4 | 4.90 | 98.00 |
| 4 x 4 x 1/4 | 6.60 | 132.00 |
| 4 x 4 x 3/8 | 9.80 | 196.00 |
Yes, we offer custom sizes for Inconel 600 Channel to meet specific project needs. Our team at Josh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
**Inconel 600 Channels** find extensive use in industries that demand exceptional heat and corrosion resistance. In aerospace, they are utilized in turbine components, exhaust systems, and heat shields. The chemical and petrochemical sectors use them in reactors, piping systems, and heat exchangers. Power generation facilities incorporate Inconel 600 Channels in boiler components, furnace linings, and superheaters. In the marine industry, they are applied in seawater handling systems, offshore equipment, and structural frameworks. Their remarkable mechanical properties make them a go-to choice for these challenging environments.
