Smith Fittings, a reputable manufacturer and supplier located in Canberra, Australia, specializes in high-quality **Incoloy 800 Foils**. These foils are well-known for their outstanding high-temperature strength, resistance to oxidation, and durability against corrosion. Designed to meet the rigorous demands of chemical, industrial, and power generation sectors, they maintain their structural integrity and performance even under extreme thermal and mechanical pressures. Smith Fittings prides itself on precision manufacturing, ensuring consistent thickness and a superior surface finish while complying with international quality standards. With a solid reputation for reliability and long-lasting durability, Incoloy 800 Foils from Smith Fittings are perfect for critical components found in furnaces, heat exchangers, boilers, and other high-temperature settings that require top-notch performance and safety.
**Incoloy 800 Foils** are nickel-iron-chromium alloys made up of **Nickel (30–35%)**, **Iron (39–45%)**, and **Chromium (19–23%)**, along with small amounts of **Carbon, Titanium, and Aluminum**. They boast impressive mechanical properties, including a **tensile strength of 485–620 MPa**, a **yield strength of 205–275 MPa**, and good elongation, which provides excellent ductility, toughness, and thermal stability in high-temperature and corrosive environments.
Specifications : ASTM / ASME SB 409
Size : 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange)
Grade : Incoloy Alloy 800 (UNS No. N08800) Coils & Strips
Hardness : Soft, Hard, Half Hard, Spring Hard, etc.
Finish : Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated)
Other services : Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | GOST | OR | BS | JIS | EN |
| Incoloy 800 | N08800 | 1.4876 | Z8NC32-21 | ЭИ670 | XH32T | NA 15 | NCF 800 | X10NiCrAlTi32-20 |
| Incoloy 800 | C | Cr | Fe | S | Ni | Mn | Si | Cu |
| 0.10 max | 19.00 – 23.00 | 39.50 min | 0.015 max | 30.00 – 35.00 | 1.50 max | 1.00 max | 0.75 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Josh Sheets and Plates based in Canberra, Australia, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Incoloy 800 Foils offer exceptional advantages, making them ideal for demanding industrial applications. Their high-temperature strength ensures reliable performance in extreme environments, while excellent oxidation and carburization resistance prolongs service life. The alloy’s superior corrosion resistance in acidic and oxidizing conditions adds to its versatility. Incoloy 800 foils maintain mechanical stability under thermal cycling, reducing deformation risks. Their ease of fabrication and welding supports diverse manufacturing needs. Commonly used in heat exchangers, petrochemical equipment, and nuclear power plants, these foils are a trusted choice for durability and operational efficiency.
| Size (mm) | Weight per (Kg) | Size (mm) | Weight per (Kg) |
|---|---|---|---|
| 2000 x 1000 x 2.0 | 32.7 | 2000 x1000 x 0.9 | 14.7 |
| 3000 x 1500 x 1.5 | 55.3 | 2500 x1250 x 0.7 | 17.9 |
| 3000 x 1500 x 2.0 | 73.7 | 2000 x1000 x 1.0 | 16.4 |
| 2500 x 1250 x 1.5 | 38.4 | 2000 x1000 x 0.7 | 11.5 |
| 3000 x 1500 x 3.0 | 112.0 | 2000 x1000 x 1.5 | 24.6 |
| 2500 x 1250 x 2.0 | 51.2 | 2500 x1250 x 0.9 | 23.0 |
| 2000 x 1000 x 2.5 | 40.9 | 2500 x1250 x 1.0 | 25.6 |
| 2500 x 1250 x 2.5 | 63.9 | 3000 x1500 x 1.0 | 36.8 |
| 2500 x 1250 x 3.0 | 77.5 | 3000 x1500 x 1.2 | 44.2 |
| 3000 x 1500 x 2.5 | 92.1 | 2000 x1000 x 1.2 | 19.6 |
| 2000 x 1000 x 3.0 | 49.6 | 2500 x1250 x 1.2 | 30.7 |
Yes, we offer custom sizes for Incoloy 800 Foils to meet specific project needs. Our team at Josh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
These **Incoloy 800 Foils** are extensively used in industries that demand high-temperature resistance and corrosion protection. Common applications include **furnace components, heat exchangers, boiler parts, chemical processing equipment, and nuclear power systems**. They are also found in **petrochemical, industrial manufacturing, and aerospace sectors**, where components must endure both oxidizing and reducing conditions at elevated temperatures. The remarkable formability, weldability, and durability of Incoloy 800 Foils from Smith Fittings make them an ideal choice for fabricating essential high-performance components in challenging industrial and chemical environments.
