Smith Fittings, a top-notch manufacturer and supplier located in Canberra, Australia, proudly offers high-quality **Haynes 25 / L605 Sheets and Plates**. These materials are celebrated for their remarkable strength at high temperatures, impressive resistance to corrosion, and overall durability. Designed to meet the rigorous demands of aerospace, chemical, and industrial applications, these sheets and plates are built to maintain their structural integrity and deliver reliable performance even under extreme thermal and mechanical pressures. Smith Fittings is committed to precision manufacturing, ensuring consistent thickness and a superior surface finish while meeting international quality standards. Known for their long-lasting performance and dependability, Haynes 25 / L605 Sheets and Plates are perfect for critical components in high-temperature and corrosive settings, providing exceptional structural stability and safety.
**Haynes 25 / L605 Sheets and Plates** are cobalt-based superalloys made up of **Cobalt (≈45%)**, **Chromium (≈20%)**, **Nickel (≈15%)**, **Tungsten (≈12%)**, and **Iron (≈3%)**, along with trace amounts of **Carbon, Manganese, and Silicon**. They boast impressive mechanical properties, featuring a **tensile strength of 1,100–1,300 MPa**, a **yield strength of 700–900 MPa**, and outstanding resistance to creep and oxidation. This unique blend of elements ensures excellent ductility, toughness, and thermal stability, even in the most extreme operating conditions.
| Standard Specification : | AMS 5759, AMS 5537 |
| Dimensions : | AMS, AMS, API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat T |
| Grade | C% | Si≤ % | Mn≤ % | P≤ % | S≤ % | Cr% | Ni% | Co% | Fe % | W % |
| Haynes 25 / L605 | 0.05-0.15 | 0.40 | 2.00 | 0.02 | 0.015 | 19.0-21.0 | 9.00-11.0 | Rest | ≤ 3.00 | 14.0-16.0 |
| Grade | 0.2% Yield strength Rp ≥ N/mm² | Tensile strength Rm N/mm² | Elongation A5 | Resistant on air up to°C | Modulus of elasticity kN/mm² |
| Haynes 25 / L605 | 345 | 830-1130 | 25 | 1090 | 225 |
| STANDARD | Material No | EN Designation | UNS | Alloy |
| Haynes 25 / L605 | 2.4964 | CoCr20W15Ni | R30605 | 25 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Haynes 25 (L605) sheets and plates provide exceptional high-temperature strength and outstanding resistance to oxidation, carburization, and sulfidation, making them ideal for harsh environments They wear well and resist corrosion ensure durability, especially in chemical applications and aerospace applications . Excellent mechanical strength is maintained up to 1800°F (980°C) and allows for high formability and weldability. The cobalt-based structure of the compound provides durability and creep resistance, supporting reliability under extreme stresses. These features make Haynes 25 paper and plate the preferred choice for high-performance applications in hostile environments.
| Density | Lb/in3 | 0.327 |
| g/cm3 | 9.07 | |
| Melting Point | oF | 2425-2570 |
| oC | 1330-1410 | |
| Specific Heat | Btu/lb-oF | 0.096 |
| J/kg-oC | 403 | |
| Expansion Coefficient | 25-100oC | 12.8 |
| 70-200oF | 7.1 | |
| Thermal Conductivity | W/m-oC | 10.5 |
| BTU-in/hr-ft2–oF | 72 | |
| Electrical Resistivity | µohm-cm | 88.6 |
| µohm-in | 34.9 |
**Haynes 25 / L605 Sheets and Plates** find their place in various industries that demand exceptional high-temperature performance, corrosion resistance, and mechanical reliability. Common applications include **gas turbine components, aerospace engine parts, combustion chambers, industrial furnaces, and chemical processing equipment**. They are also utilized in **power generation, heat exchangers, and high-temperature manufacturing systems**, where maintaining structural stability in the face of intense heat and oxidizing environments is crucial. The remarkable formability, weldability, and durability of Haynes 25 / L605 Sheets and Plates from Smith Fittings make them the go-to choice for fabricating high-performance components.
